Restricted access
Compact overall length helps in confined launch arrangements.
Steel pipe ramming
Compact ramming power for restricted access.
The TERRA TR 200 Mini combines a compact 0.90 m tool length with 155 tonnes of impact force.
Approved specification
TERRA TR 200 Mini
A short, compact steel pipe ram for installations where working space is limited.
150–400 mm
Pipe diameter range
155 t
Impact force
4 m³/min
Air demand
0.90 m
Tool length
Project fit
Specify the complete installation.
Practical air demand
Approved 4 m³/min air demand supports smaller system planning.
Correct accessories
Select the plate, ring and support arrangement around the pipe.
TA guidance
Share the application details for a configuration review.
TERRA support in the UK
Discuss TERRA TR 200 Mini with TA Drilling
Share the pipe size, crossing length, access, ground conditions and site constraints so the complete system can be reviewed.
